PathMaster® Manual Rev. H 6/03
- 19 -
The following tables display the command variables that an operator may wish to change.
Table 3 – Coordinate System Locations
Axis
Locations X Y Z W
Auto Purge Location PT_APG[0] PT_APG[1] PT_APG[2] PT_APG[3]
Solvent Cup Location PT_SOL[0] PT_SOL[1] PT_SOL[2] PT_SOL[3]
Calibration Location PT_CAL[0] PT_CAL[1] PT_CAL[2] PT_CAL[3]
Standby Location PT_SBY[0] PT_SBY[1] PT_SBY[2] PT_SBY[3]
Table 4 – Variable Explanations
Variable Explanation
AP_EN Default value for auto purge. 1=on, 0=off.
AP_LEN Length of auto purge, in milliseconds.
AP_TIME Time between auto purges, in millesends.
SLP_TM Sleep timer value for solvent rest, in millesends.
SO_EN Solvent rest enable / disable. 1=enable, 0=disable.
Once Main program modifications have been made, the new program must be downloaded to the controller
using the PathMaster® Download -> Main function.
