Quickie Groove - Seat to Floor Height Matrix (Power Recline;Asap)

RHYTHM SERVICE MANUAL
2009
PAGE 8.8
SUNRISE MEDICAL
Seat to Floor Height Matrix (cont)
Actual
STFH
(in)
Post
Position
Short
Post
Position
Med
Post
Position
T all
Post
Position
Extra
T all
Pre-Tilt
Angle
(degr ees)
Power Recline
No Module
17.1 1 / A 3 / C 4 / D 5 /E
No M odule with
Transit
17.6 2 / B 3 / C 4 / D 5 /E
Tilt
17.9 1 / A 3 / C 4 / D 5 /E
T ilt with T r ansit
18.4 2 / B 3 / C 4 / D No Go
0
No Module
18.2 1 / A 3 / C 4 / D 5 /E
No M odule with
Transit
18.7 2 / B 3 / C 4 / D No Go
Tilt
19.0 1 / C 3 / D 4 / E No Go
T ilt with T r ansit
19.6 2 / C 4 / E 5 / E No Go
3
No Module
19.3 1 / A 3 / C No Go No Go
No M odule with
Transit
19.8 2 / B 3 / C No Go No Go
6
No Module
20.4 1 / A No Go No Go No Go
No M odule with
Transit
20.9 2 / B No Go No Go No Go
9
Asap Seating
No Module
17.1 1 / A 3 / C 4 / D 5 /E
No M odule with
Transit
17.6 2 / B 3 / C 4 / D 5 /E
Tilt
18.6 1 / A 3 / C 4 / D 5 /E
T ilt with T r ansit
19.1 2 / B 3 / C 4 / D 5 /E
0
No Module
18.2 1 / A 3 / C 4 / D 5 /E
No M odule with
Transit
18.7 2 / B 3 / C 4 / D No Go
Tilt
19.7 1 / C 3 / D 4 / E No Go
T ilt with T r ansit
19.5 2 / C 3 / D 4 / E No Go
3
No Module
19.3 1 / A 3 / C No Go No Go
No M odule with
Transit
19.8 2 / B 3 / C No Go No Go
6
No Module
20.4 1 / A No Go No Go No Go
No M odule with
Transit
20.9 2 / B No Go No Go No Go
9
Section 8
