INTRODUCTION
7
©2002 Sunrise Medical
Basic Setup
When setting up the components of the chair, complete the following checklist to ensure proper and safe operation
of the equipment.
Check :
Are the batteries fully charged? □
Test battery voltage with D.C. meter across the terminals of batteries. The measurement should be above a.
12 volts D.C.
If not, fully charge the batteries.b.
Are all necessary power components installed and connected ? □
Input device (normally Joystick) a.
Cable from Joystick to the Bus Line b.
Control Module; for the Groove located in the Center between the 2 batteries c.
Control Module; for the Rhythm located at back of chair behind shroud d.
Are all necessary connections fastened or inserted? □
Battery connectors to the batteries a.
Cable between Joystick and the Control b.
Both Motor Connectors to the Control Module.c.
Is the Drive Gear engaged? □
With the power off the chair should not move if pushed from behind. a.
If the chair moves when pushed, refer to Chapter 4 for proper operation of Drive Gear Engagement.b.
Does 7 bar Display light up when Power On/Off switch is depress? □
If no - recheck the 4 checks listed above then refer to Chapter 8 Diagnostics.a.
If yes – the Power Wheelchair is ready to driveb.
