Quickie Groove User Manual

RHYTHM SERVICE MANUAL
2009
PAGE 8.10
SUNRISE MEDICAL
Section 8
Asap Fixed Center mount Footrest Mounting Matrix
Part #
014945
Position
Part #
014941
Position
Leg
Length
G round C learance T ilt G round C learance Non-Tilt
S TF 18 ½” 19
½”
20 ½” 21 ½” 17 ¼” 18 ¼” 19 ¼” 20 ¼”
1 A 13 ½” 4 5/8” 5
5/8”
6 5/8” 7 5/8” 3 3/8” 4 3/8” 5 3/8” 6 3/8”
2 A 14 ½” 3 5/8” 4
5/8”
5 5/8” 6 5/8” 2 3/8” 3 3/8” 4 3/8” 5 3/8”
3 A 15 ½” 2 5/8” 3
5/8”
4 5/8” 5 5/8”
1 3/8” 2 3/8” 3 3/8” 4 3/8”
4 A 16 ½” 1 5/8” 2
5/8”
3 5/8” 4 5/8” 3/8” 1 3/8” 2 3/8” 3 3/8”
5 A 17 ½” 5/8” 1
5/8”
2 5/8”
3 5/8” NOGO 3/8” 1 3/8” 2 3/8”
R E D S HADE D AR E AS AR E NO-GO’s
DEFAULT CONFIGURATEION FROM FACTORY
