QuickLabel Kiaro! 200 - Inside the Printer

Introduction
Kiaro! 200 User Guide 23
Inside the Printer
[1]
[3]
[4]
[2]
# Part Description
1 Upper Unit Release Lever Push this lever up to release the upper unit.
2 Ink Tanks Black (Bk), cyan (C), magenta (M), and yellow (Y) ink tanks are
loaded.
3 Transport Unit The transport unit feeds label media.
4 Maintenance Cartridge Ink used to clean the print head is collected here.
