• Head - Select the color of the missing line and the affected printhead. In the
previous example, a missing line appeared in the black pattern of the right
printhead (K1).
• Page - Choose whether the missing line is on the first or second test page for
the selected color. In the previous example, the missing line occurred on page
one of the two-page black pattern.
• Row - Enter the row number of the missing line. In the previous example, the
missing line occurred in row 50.
• Column - Enter the column number of the missing line. In the previous
example, the missing line occurred in column 9.
Choose Add to List to add the missing line to the adjustment list. Repeat this
process for all missing lines.
9 If necessary, you can delete items from the adjustment list by selecting the item
and choosing Remove from List.
10 When you are finished entering adjustments, choose Print Confirmation Pattern.
The pattern will be reprinted, but with your adjustments applied. Examine the
pattern to ensure the missing lines you entered now appear correctly.
11 Choose Close when you are finished entering missing nozzle adjustments.
Related Topics:
- Cleaning Printheads on page 61
Adjusting the Top-of-Form Threshold
If any of the following errors occur while using reflective mark media, you may need to
calibrate the top-of-form sensor threshold. The following table describes the types of
adjustments needed for each error condition.
Error # Error Name
Sensor Adjustment
Adjust-
ment ValueInternal Cutter
1002 No paper Increase NA +0.2V
1102 Paper length is too short Increase NA +0.2V
1104 Paper length is too short NA Increase +0.2V
1301 Paper jam occurred Decrease NA -0.2V
1302 Paper jam occurred Decrease NA -0.2V
1304 Paper jam occurred NA Increase +0.2V
1305 Paper jam occurred NA Decrease -0.2V
1306 Paper jam occurred NA Increase +0.2V
