Appendix E: Hub Site Synchronization
WinLink User and Installation Guide Version 1.750 13-154
Table
13-3: External Pulse Status
Status Description Text Color
Not Detected Sync pulses not
detected
Green
Generating Unit is HSM and is
generating RFP pulses
Green
Generating and
Detected
Unit is HSM and
generating RFP pulses
and is also receiving
pulses from another
unit. Incorrect
configuration.
Red
Generating and
Improper Detected
Unit is HSM and
generating RFP pulses
and is also receiving
incorrect pulses from
another unit. Incorrect
configuration.
Red
Detected HSC detecting pulses Green
Improper Detected Incorrect RFP and BW
configuration
Red
Multiple Sources
Detected
More than one HSM
generating pulses.
Incorrect
configuration.
Red
Æ To configure the Operational States of the hub site unit
1. Click the Enabled check box
2. Click the Configure button
The Hub Site Configuration dialog box with the current status of the
ODUs is displayed.
3. Select the type of unit configuration from the drop-down list.
Because only the relevant options are displayed according to the
hardware configuration of each unit, usually the remote site will
have only the Independent Unit option available.
4. Select the appropriate RFP radio button. Some RFP options may be
disabled depending on the BW previously selected.
Take care to avoid incorrect configuration of bandwidth, RFP or to set
multiple Hub Sync Masters, as system interference can occur.
Note
