Configuring the Site
WinLink User and Installation Guide Version 1.750 5-90
parameters are located under the Advanced tab of the Configuration
dialog box:
Figure
5-17: Bridge Configuration - Site Configuration dialog box
ODU Bridge Mode
This parameter controls the ODU mode with two optional values,
• Hub Mode – in Hub mode the ODU transparently forwards the
all the packets over the wireless link.
• Bridge Mode – In Bridge mode the ODU performs both
learning and aging, the aging time of the ODU is fixed at 300
seconds.
Note:
Changing these modes requires system reset.
IDU Aging time
This parameter controls the IDU aging time.
The IDU has a 2047 MAC address-learning table. The aging time
parameter controls the time each MAC address is dropped from the
table.
Default value is 300 seconds.
