Chapter 17
Appendix I - Product
Specification Table
Table
17-1: Product Specification Table
Frequency (MHz)
Transmit Power
(dBm)
Product Band
Min Max Step TPC Min Max
Antenna
Gain (dBi)
EIRP
(dBm /
Watt)
DFS ACS
1 WL1000-ODU/F23/HP/EXT
2.3
2312 2387 5 16 16 24 39 / 7.9 +
2 WL1000-ODU/F24/ETSI/EXT 2412 2472 5 -4 -4 24 19 / 0.1 +
3 WL1000-ODU/F24/HP/EXT 2312 2472 5 + 12 16 24 39 / 7.9
4 WL1000-ACCESS/F24/HP/EXT 2312 2472 5 + 12 16 24 39 / 7.9
5 WL1000-ODU/F24/FCC/EXT 2412 2462 5 + 12 18 24 41 / 12.6 +
6 WL1000-ACCESS/F24/FCC/EXT 2412 2462 5 + 12 18 24 41 / 12.6 +
7 WL1000-ODU/F24/FCC/EXT/PoE 2412 2462 5 + 12 18 24 41 / 12.6 +
8 WL1000-ODU/F24/FCC/INT 2412 2462 5 + 12 18 16 34 / 2.5 +
9 WL1000-HE/ODU/F24/FCC/INT 2412 2462 5 + 13 19 16 35 / 3.17 +
10 WL1000-HE/ODU/F24/FCC/EXT
2.4
2412 2462 5 + 13 19 24 42 / 15.8 +
11 WL1000-ODU-HE/F25/BRS/INT 2500 2690 15 22 17.5
39.5 /
8.9 -
12 WL1000-ODU-HE/F25/BRS/EXT
2.5
2500 2690 15 22 24 45 / 31.6 -
13 WL1000-ODU/F49/HP/EXT 4950 4980 5 8 23 27 49 / 79.4 +
14 WL1000-ODU/F49/FCC/EXT 4950 4980 5 9 15 21 35 / 3.2 +
15 WL1000-HE/ODU/F49/FCC/EXT 4950 4980 5 11 17 21 37 / 5 +
16 WL1000-HE/ODU/F49/HP/EXT
4.9
4950 4980 5 8 23 21
44 /
25.11 +
17 WL1000-ODU/F53/HP/EXT 5160 5335 5 + 4 16 28 43 / 20.0 +
18 WL1000-ODU/F53/ETSI/EXT 5180 5320 20 + -2 15 28 42 / 15.8 +
19 WL1000-ODU/F53/HP/EXT/PoE 5160 5335 5 + 4 16 28 43 / 20.0 +
20 WL1000-ODU/F53/FCC/EXT 5260 5330 5 2 2 28 29 / 0.8 +
21 WL1000-ODU/F53/FCC/INT
5.3
5260 5330 5 + 4 8 22 30 / 1.0 +
22 WL1000-ODU/F54/ETSI/EXT 5500 5700 20 + 2 8 28 35 / 3.2 + +
23 WL1000-ODU/F54/ETSI/INT 5500 5700 20 + 2 8 22 30 / 1.0 + +
24 WL1000-HE/ODU/F54/ETSI/INT 5500 5700 20 + 2 8 22 30 / 1.0 + +
25 WL1000-ODU/F54/ETSI-HG/EXT 5500 5700 20 + -3 3 28 30 / 1.0 + +
26
WL1000-HE/ODU/F54/ETSI-
LG/EXT
5500 5700 20 + -3 15 28 42 / 15.8 + +
27 WL1000-ODU/F54/HP/EXT 5500 5700 20 + 4 18 28 45 / 31.6 +
28 WL1000-HE/ODU/F54/HP/EXT
5.4
5500 5700 20 + 4 23 28 50 / 100 +
