1.5.3 Module Locations - Back
The back of the PixelStor 5000 provides easy access to the hot plug RAID controller modules,
fan modules and power supply modules. All of the device and power connections are externally
accessible and are located in the back of the system.
Figure 1-4 Rear Panel
1.- Power Supply 0
5.- Power Supply 1
2.- Controller 0
6.- COM 0 (rightmost)
3.- SAS Connectors ( = Out = In)
7.- USB Port
4.- Controller 1
8.- 5 NIC Ports RJ45)
Figure 1-5 Rear Panel
