Diagnostics and Troubleshooting
Code ID Description Recommended Actions
3045 .31
Authorization
denied.
1. Check the steering guidance controller
(SGC)cabling is properly connected.
2. Check connectors for bent or pins pushed in and
not making proper connection.
5238
.2 Invalid curvature.
1. Check cabling and connections to the steering
partner (steering valve).
2. Cycle power to the steering valve.
3. Update the steering partner/valve software.
.31
Loss of SCU com-
munication.
The steering guidance controller (SGC) previously
registered a steering partner but is not currently
communicating with the expected partner.
1. Check cabling and connections to the steering
partner (steering valve).
2. Cycle power to the machine.
3. Check the software version of the steering part-
ner (steering valve) and confirm compatibility
with the steering guidance controller (SGC) soft-
ware.
5241 .31
Disengage switch
is in the off pos-
ition.
1. Check the disengage switch status in the uni-
versal terminal (UT). Status in the UTshould only
be active (red status indicator) when then steer-
ing wheel is moving.
2. If the disengage switch status is red (activity
detected) while the steering wheel is stationary,
increase the disengage threshold. Review the
"Steering Disengage Settings" on page91 for
assistance.
Note: For best results, set the disengage value
to the minimum value necessary to disengage
auto-steering.
3. Check the disengage switch cabling and con-
nections.
151
To Next Page
