Diagnostics and Troubleshooting
Code ID Description Recommended Actions
invalid.
.31
Lockout switch
pressed.
Toggle the lockout switch OFF. If the issue persists,
check the lockout switch cabling and connections.
522240
.16 GGA rate high.
Cycle power to the machine.
.18 GGArate low.
.31 No GPScomm.
1. Leave the SGC powered on for 10 minutes.
2. Cycle power to the machine.
522242
.16 ZDA rate high.
Cycle power to the machine.
.18 ZDA rate low.
522250
.0 End of line error.
Contact the Raven Technical Service team for addi-
tional assistance.
.15
Maximum point
space error.
.16
Segment angle
error.
.17
Minimum point
space error.
.2 Curvature invalid.
1. Reset or update the field computer.
2. Contact a local Raven dealer for additional
assistance.
.31
No guidance
path.
1. Cycle power to the Raven field computer or
UTdisplay.
2. Ensure the Raven field computer is used for guid-
ance.
3. Start a job and create an A-B guidance path.
.7
Maximum cross-
track error (XTE)
exceeded.
1. Recalibrate the auto-steer system, including the
hydraulic calibration.
2. Check hydraulic steering performance. Refer to
the "Wheel Control Settings" on page79 for
assistance.
.8
Look-ahead too
large.
Contact the Raven Technical Service team for addi-
tional assistance.
