Diagnostics and Troubleshooting
Code ID Description Recommended Actions
3. Contact a local Raven dealer for additional
assistance.
523885
.31
PWMOut ! =
PWM in.
Amperage supplied to the left or right PWM valve does
not match return.
1. Ensure cable connections are properly seated.
2. Contact a local Raven dealer for additional
assistance.
.5
PWM pwr cur-
rent (mA) low.
Amperage supplied to the left and right solenoids is
too low.
1. Ensure cable connections are properly seated.
2. Check cabling for broken or frayed wiring.
.6
PWM pwr cur-
rent (mA) high.
Amperage supplied to the left and right solenoids is
too high.
1. Ensure cable connections are properly seated.
2. Check cabling for shorts or loose connections.
523886 .6
PWM pwr cur-
rent (mA) fail.
Unexpected amperage supplied to the left and right
solenoids while auto-steering is not active.
1. Ensure cable connections are properly seated.
2. Check cabling for shorts or loose connections.
523887
.5
PWMlgnd (left
ground) current
(mA) low.
Amperage supplied to left solenoid is too low.
1. Ensure cable connections are properly seated.
2. Check cabling for broken or frayed wiring.
.6
PWMlgnd (left
ground) current
(mA) high.
Amperage supplied to left solenoid is too high.
1. Ensure cable connections are properly seated.
2. Check cabling for shorts or loose connections.
523888 .6
PWM lgnd (left
ground) current
fail.
Unexpected amperage supplied to the left solenoid
while auto-steering is not active.
1. Ensure cable connections are properly seated.
2. Check cabling for shorts or loose connections.
