Chapter7
Code ID Description Recommended Actions
523889
.5
PWMrgnd (right
ground) current
(mA) low.
Amperage supplied to right solenoid is too low.
1. Ensure cable connections are properly seated.
2. Check cabling for broken or frayed wiring.
.6
PWMrgnd (right
ground) current
(mA) high.
Amperage supplied to right solenoid is too high.
1. Ensure cable connections are properly seated.
2. Check cabling for shorts or loose connections.
523890 .6
PWMrgnd (right
ground) current
(mA) fail.
Unexpected amperage supplied to the right solenoid
while auto-steering is not active.
1. Ensure cable connections are properly seated.
2. Check cabling for shorts or loose connections.
523891
.31 DBOut ! = DB in.
Amperage supplied to double blocker solenoid does
not match amperage return.
1. Ensure cable connections are properly seated.
2. Check for supply voltage on the connections to
the machine steering valve.
3. Contact a local Raven dealer for additional
assistance.
.5
DBpwr(power)
current
(mA)low.
Amperage supplied to double blocker solenoid too
low.
1. Ensure cable connections are properly seated.
2. Check cabling for broken or frayed wiring.
3. Check for supply voltage on the connections to
the machine steering valve.
.6
DBpwr (power)
current (mA)
high.
Amperage supplied to double blocker solenoid is too
high.
1. Ensure cable connections are properly seated.
2. Check cabling for shorts or loose connections.
3. Check for supply voltage on the connections to
the machine steering valve.
