Connecting the System Components
These figures show the cable connections between the SR1500 system components.
See also Polarization Configuration, on page 36, and Appendix D – Basic Cable Kit
Contents, on page 44.
SR1500 Dual Pol Connectivity
Figure 40: SR1500 Dual Pol Connectivity
Table 4: Wiring connections for SR1500 Dual Pol Connectivity
From
Connector
To
Connector
Cable P/N
Purpose
1
Ant. Ctrl
TNC L-band
Rx ODU Out
DC & Control
ACU
TNC L-band
Rx ACU Out
DC & Control
CBM1000010
OR
CBM0000003 *
L-band Rx
1b
Ant. LB
TNC L-band Rx
STB 2
F Type – STB
RF IN
CB101738
OR CB101666 *
1c
Ant. HB
STB 3
2
ACU
F-type plug-M
STB 1
F-type plug-
M
CBM0000021
3
Battery
ACU
CBM0000165
12-24 VDC
* Cables are 12 m or 6 m. See Appendix D – Basic Cable Kit Contents, on page 44.
