Accessing the ACU Web Interface
The following procedure describes how to access pages in the Web interface.
Buttons in the Interface Pages
Read-only pages include a Refresh button that updates the parameters
displayed to current values.
Pages that allow editing values include the following buttons:
o Submit button to save the current changes,
o Reset button to clear the screen of entries and start over,
o Cancel button to return to the main page without saving.
The interface uses Java Script to calculate input parameter values. It
is recommended to allow the Web browser to run blocked content.
To access and work with the ACU Web interface:
1. Connect a LAN cable between PC LAN port and Ethernet (LAN) port of ACU.
2. Configure the PC with IP Address 192.168.1.10 Mask 255.255.255.0.
The PC IP address should belong to the same subnet address range
as the ACU.
3. Open a web browser and browse to 192.168.1.250.
The default ACU IP address is shown.
