Configuring the Antenna with the ACU Web
Interface
The ACU Web interface provides an easy to use graphical interface for antenna
system operation and maintenance. After you log in (see Accessing the ACU Web
Interface, on page 50), the following menu options appear:
Table 13: ACU web interface menus
Menu option
Description
1
IDU
Displays general IDU (ACU) information.
See Monitoring ACU Parameters, on page 52.
2
Antenna
Used to edit satellite parameters, or to create or delete a
satellite.
See Configuring ACU and Antenna Parameters, on page 55.
3
Satellite
Used to edit satellite parameters, or to create or delete a satellite.
See Configuring Satellite Settings, on page 57.
4
Networking
Used to change the IP address of the ACU, if required. This is not a
commonly used feature. The factory default IP address is
192.168.1.250. You can also verify the IP address from the ACU
front panel. See Configuring Network Settings, on page 61.
5
Modem
Used to select the satellite modem. See Error! Reference source
not found., on page Error! Bookmark not defined..
6
Receiver
Used to select a satellite TV receiver. Not relevant for two-way
communications.
7
Antenna Log
Used to view alarm messages. See Antenna Log, on page 66.
8
Maintenance
Used to issue commands or verify parameters for diagnostic
purposes. Only for trained personnel familiar with the ACU
commands. An improper command can cause the antenna to
malfunction. See Maintenance, on page 67.
9
RAYSAT
Takes you to Gilat RaySat’s website. You must have an Internet
connection for this capability.
10
Logout
Logs the user out from the ACU Configuration. See Logging Out, on
page 69.
