Appendix G – Specifications
The specifications for the SR1500 are listed in the following table.
Table 40: Technical specifications for SR1500
115 L x 90 W x 24 H cm (45 x 35 x 9.45 in)
18 L x 23 W x 7 H cm (7 x 9 x 3 in)
10 ± 1 dB/K @ 30° elevation
Full Band 10.7 - 12.75 GHz
Typical Power Consumption
Maximum Power Consumption
Dual linear, automatically adjusted (V&H)
V/H or RHCP/LHCP Simultaneous on 1.5GHz band 3
Simultaneous connections
Elevation look angle range
Automatically adjusted, 10° - 80°
Automatically adjusted, 360° continuous
Automatically adjusted, -180° to +180°
<1 minute, fully automated with integrated GPS
<10 seconds (when LoS blockage is <2 minutes),
integrated gyro
