Reliable Controls SMART-Space Controller User Manual

RC-TOOLKIT BACNET MSET TOOL
48
 2012-2015 Reliable Controls Corporation
4 Enter a number in the Starting Device ID field that corresponds to the Reliable
Controls standard for device numbering (refer to the Reliable Controls BACnet
manual). Ensure that the entered number in the Starting Device ID field poses
no possible Device ID conflicts. After connecting over the BACnet network, the
SSC Setup application determines the host BACnet device number, and
calculates a Starting Device ID according to the Reliable Controls standard for
device numbering. In this example, the SSC Setup application determined that
the host device number was 124, resulting in the Starting Device ID field being
automatically set to 124300 (124 x 1000 + 300). The user can enter a different
Starting Device ID, if preferred.
5 After the desired starting numbers have been entered, click the Auto Address
button to automatically fill in the Device ID and MAC# for unconfigured
SMART-Space Controllers. The BACnet MSet Tool will automatically skip any
MAC# or Device ID values that are already in use on the selected network.
FIGURE 42: RC-TOOLKIT, BACNET MSET DIALOG BOX
