PG-FP5 CHAPTER 4 PROGRAMMING GUI USAGE
R20UT0008EJ0400 Rev. 4.00 Page 58 of 240
Jul 15, 2010
Figure 4-19. Result When Self-Testing Program Has Been Completed Normally <Result Dialog Box>
Figure 4-20. Example of Result When Self-Testing Program Has Been Completed Abnormally
<Action Log Window>
>selftest
***** CAUTION *****
Remove any plugs from Target- and Remote-Connector before starting.
Any hardware attached to those connectors may be damaged by this test !
***** CAUTION *****
Target- and Remote-connector unplugged ?
If yes, press 's' to start the test: s
FPGA Test: PASS
Power Supply Test: PASS
Target- and Remote-Interface Test: FAIL
Selftest FAILED.
>
Figure 4-21. Example of Result When Self-Testing Program Has Been Completed Abnormally
<Result Dialog Box>
