PG-FP5
CHAPTER 4
PROGRAMMING GUI USAGE
R20UT0008EJ040
0 Rev. 4.00
Page 83 of 240
Jul 15, 2010
S
ave As...
button
Clicking this button opens th
e dialog box for
overwriting t
h
e current settings made in the
Device Setup dialog
box
to the existing ESF file, or saving as another file.
S
pecif
y the file and then click the
O
pen
butt
on. Note that the PR5 file is also copied to the destination folder.
Figure
4-55. [Save as...] Dialog Box
82
84
