Table 4-2. Channels for Communication Between FP5 and Target Device (2/2)
Item on Screen Description
CSI-Internal-OSC
SIO (3-wire clocked communication port) (using internal oscillator) * In the case of 78K0 (All
Flash)
UART-Ext-FP5CLK UART (asynchronous communication port) (using FP5 clock) *In the case of 78K0 (All Flash)
UART-Ext-OSC
UART (asynchronous communication port) (using external oscillator) * In the case of 78K0 (All
Flash)
UART-Internal-OSC
UART (asynchronous communication port) (using internal oscillator) * In the case of 78K0 (All
Flash)
UART
Single-wire UART (asynchronous communication port) (using internal oscillator) * In the case of
78K0 or 78K0R (All Flash)
[Pulse number]
V
PP or the FLMD0 count corresponding to the selected communication mode is displayed. This item cannot be
changed.
[Speed] List box
Select the communication rate of the selected communication channel.
Remark For the available communication speed, refer to the user’s manual of the target device.
<When UART-ch0, UART-ch1, UART-ch2, UART-ch3, UART-Ext-FP5CLK, UART-Ext-OSC, UART-Internal-OSC,
or UART is selected>
• 9600 Baud
• 19200 Baud
• 31250 Baud
• 38400 Baud
• 57600 Baud
• 76800 Baud
• 115200 Baud
• 125000 Baud
• 128000 Baud
• 153600 Baud
• 250000 Baud
• 500000 Baud
• 1000000 Baud
<When SIO-ch0, SIO-ch1, SIO-ch2, SIO-H/S or CSI-Internal-OSC is selected>
• 9.8 kHz
• 39 kHz
• 156 kHz
• 625 kHz
• 2500 kHz
• 5000 kHz
<When IIC-ch0, IIC-ch1, IIC-ch2 or IIC-ch3 is selected>
• 10k Baud
• 20k Baud
• 50k Baud
