RL78/G13 CHAPTER 29 ELECTRICAL SPECIFICATIONS
R01UH0146EJ0100 Rev.1.00 997
Sep 22, 2011
Caution The pins mounted depend on the product. Refer to 2.1.1 20-pin products to 2.1.14 128-pin products,
and 2.1.15 Pins for each product (pins other than port pins).
(2) Flash ROM: 96 to 256 KB of 30- to 100-pin products
(T
A = −40 to +85°C, 1.6 V ≤ EVDD0 = EVDD1 ≤ VDD ≤ 5.5 V, VSS = EVSS0 = EVSS1 = 0 V) (1/2)
Parameter Symbol Conditions MIN. TYP. MAX. Unit
VDD = 5.0 V 2.3 mA Basic
operation
VDD = 3.0 V 2.3 mA
VDD = 5.0 V 5.2 8.5 mA
fIH = 32 MHz
Note 3
Normal
operation
VDD = 3.0 V 5.2 8.5 mA
VDD = 5.0 V 4.1 6.6 mA fIH = 24 MHz
Note 3
Normal
operation
VDD = 3.0 V 4.1 6.6 mA
VDD = 5.0 V 3.0 4.7 mA
High-speed
operation
Note 5
f
IH = 16 MHz
Note 3
Normal
operation
VDD = 3.0 V 3.0 4.7 mA
VDD = 3.0 V 1.3 2.1 mA Low-speed
operation
Note 5
f
IH = 8 MHz
Note 3
Normal
operation
VDD = 2.0 V 1.3 2.1 mA
VDD = 3.0 V 1.3 1.8 mA Low-voltage
operation
Note 5
f
IH = 4 MHz
Note 3
Normal
operation
VDD = 2.0 V 1.3 1.8 mA
Square wave input 3.4 5.5 mA fMX = 20 MHz
Note 2
,
V
DD = 5.0 V
Normal
operation
Resonator connection
3.6 5.7 mA
Square wave input 3.4 5.5 mA fMX = 20 MHz
Note 2
,
V
DD = 3.0 V
Normal
operation
Resonator connection
3.6 5.7 mA
Square wave input 2.1 3.2 mA fMX = 10 MHz
Note 2
,
V
DD = 5.0 V
Normal
operation
Resonator connection
2.1 3.2 mA
Square wave input 2.1 3.2 mA
High-speed
operation
Note 5
fMX = 10 MHz
Note 2
,
V
DD = 3.0 V
Normal
operation
Resonator connection
2.1 3.2 mA
Square wave input 1.2 2.0 mA fMX = 8 MHz
Note 2
,
V
DD = 3.0 V
Normal
operation
Resonator connection
1.2 2.0 mA
Square wave input 1.2 2.0 mA
Low-speed
operation
Note 5
f
MX = 8 MHz
Note 2
,
V
DD = 2.0 V
Normal
operation
Resonator connection
1.2 2.0 mA
Square wave input 4.8 μ A fSUB = 32.768 kHz
Note 4
TA = −40°C
Normal
operation
Resonator connection
4.9 μ A
Square wave input 4.9 5.9 μ A fSUB = 32.768 kHz
Note 4
TA = +25°C
Normal
operation
Resonator connection
5.0 6.0 μ A
Square wave input 4.9 7.6 μ A fSUB = 32.768 kHz
Note 4
TA = +50°C
Normal
operation
Resonator connection
5.0 7.7 μ A
Square wave input 5.2 9.3 μ A fSUB = 32.768 kHz
Note 4
TA = +70°C
Normal
operation
Resonator connection
5.3 9.4 μ A
Square wave input 6.1 13.3 μ A
Supply
current
IDD1
Note 1
Operating
mode
Subsystem
clock
operation
f
SUB = 32.768 kHz
Note 4
TA = +85°C
Normal
operation
Resonator connection
6.2 13.4 μ A
(Notes and Remarks are listed on the next page.)
