RL78/G13 CHAPTER 30 PACKAGE DRAWINGS
R01UH0146EJ0100 Rev.1.00 1044
Sep 22, 2011
30.3 25-pin products
R5F1008AALA, R5F1008CALA, R5F1008DALA, R5F1008EALA
R5F1018AALA, R5F1018CALA, R5F1018DALA, R5F1018EALA
25-PIN PLASTIC FLGA (3x3)
P25FC-50-2N2-1
(APERTURE OF
SOLDER RESIST)
ITEM DIMENSIONS
D
E
w
e
A
b
x
y
y1
ZD
ZE
3.00±0.10
3.00±0.10
0.05
0.20
0.69±0.07
0.08
0.50
0.24±0.05
(UNIT:mm)
0.20
0.50
0.50
S
y1 S
A
S
DETAIL OF C PART
y
Sx21x b A B
M
e
b
0.34±0.05
0.43±0.05
0.50±0.05
0.365±0.05
R0.17±0.05
R0.165±0.05
R0.215±0.05
0.365±0.05
0.50±0.05
0.33±0.05
0.43±0.05
Sw B
ZD
ZE
INDEX MARK
B
C
A
Sw A
D
E
2.27
2.27
DETAIL OF D PART
D
1
2
EDCBA
3
4
5
(LAND PAD)
R0.12±0.05
0.33±0.05
INDEX MARK
