Page #848 background imageLoading...
Page #848 background image
RL78/G13 CHAPTER 16 INTERRUPT FUNCTIONS
R01UH0146EJ0100 Rev.1.00 829
Sep 22, 2011
16.3 Registers Controlling Interrupt Functions
The following 6 types of registers are used to control the interrupt functions.
• Interrupt request flag registers (IF0L, IF0H, IF1L, IF1H, IF2L, IF2H, IF3L)
• Interrupt mask flag registers (MK0L, MK0H, MK1L, MK1H, MK2L, MK2H, MK3L)
• Priority specification flag registers (PR00L, PR00H, PR01L, PR01H, PR02L, PR02H, PR03L, PR10L, PR10H,
PR11L, PR11H, PR12L, PR12H, PR13L)
• External interrupt rising edge enable registers (EGP0, EGP1)
• External interrupt falling edge enable registers (EGN0, EGN1)
• Program status word (PSW)
Table 16-2 shows a list of interrupt request flags, interrupt mask flags, and priority specification flags corresponding to
interrupt request sources.
Table 16-2. Flags Corresponding to Interrupt Request Sources (1/4)
Interrupt Request Flag Interrupt Mask Flag Priority Specification Flag Interrupt
Source
Register Register Register
128-pin
100-pin
80-pin
64-pin
52-pin
48-pin
40, 44-pin
36-pin
30, 32-pin
24, 25-pin
20-pin
INTWDTI WDTIIF WDTIMK WDTIPR0, WDTIPR1
√ √ √ √ √ √ √ √ √ √ √
INTLVI LVIIF LVIMK LVIPR0, LVIPR1
√ √ √ √ √ √ √ √ √ √ √
INTP0 PIF0 PMK0 PPR00, PPR10
√ √ √ √ √ √ √ √ √ √ √
INTP1 PIF1 PMK1 PPR01, PPR11
√ √ √ √ √ √ √ √ √ √ −
INTP2 PIF2 PMK2 PPR02, PPR12
√ √ √ √ √ √ √ √ √ − −
INTP3 PIF3 PMK3 PPR03, PPR13
√ √ √ √ √ √ √ √ √ √ √
INTP4 PIF4 PMK4 PPR04, PPR14
√ √ √ √ √ √ √ √ √ √ −
INTP5 PIF5
IF0L
PMK5
MK0L
PPR05, PPR15
PR00L,
PR10L
√ √ √ √ √ √ √ √ √ √ √
