Renesas RL78/G13 User Manual

RL78/G13 CHAPTER 30 PACKAGE DRAWINGS
R01UH0146EJ0100 Rev.1.00 1057
Sep 22, 2011
30.12 80-pin products
R5F100MFAFA, R5F100MGAFA, R5F100MHAFA, R5F100MJAFA, R5F100MKAFA, R5F100MLAFA
R5F101MFAFA, R5F101MGAFA, R5F101MHAFA, R5F101MJAFA, R5F101MKAFA, R5F101MLAFA
S
y
e
Sxb
M
θ
L
c
Lp
HD
HE
ZD
ZE
L1
A1
A2
A
D
E
A3
S
0.17
+0.03
−0.06
(UNIT:mm)
ITEM DIMENSIONS
D
E
HD
HE
A
A1
A2
A3
14.00±0.20
14.00±0.20
17.20±0.20
17.20±0.20
1.70 MAX.
0.125±0.075
1.40±0.05
0.25
c
θ
e
x
y
ZD
ZE
0.65
0.13
0.10
0.825
0.825
L
Lp
L1
0.80
0.886±0.15
1.60±0.20
P80GC-65-UBT
3°
+5°
−3°
NOTE
Each lead centerline is located within 0.13 mm of
its true position at maximum material condition.
detail of lead end
80-PIN PLASTIC LQFP(14x14)
0.32±0.06
b
20
40
80 21
41
61
60
1
