Renesas RL78/G13 User Manual

RL78/G13 CHAPTER 30 PACKAGE DRAWINGS
R01UH0146EJ0100 Rev.1.00 1056
Sep 22, 2011
R5F100LCABG, R5F100LDABG, R5F100LEABG, R5F100LFABG, R5F100LGABG, R5F100LHABG, R5F100LJABG
R5F101LCABG, R5F101LDABG, R5F101LEABG, R5F101LFABG, R5F101LGABG, R5F101LHABG, R5F101LJABG
ITEM DIMENSIONS
D
E
w
A
A1
A2
e
4.00±0.10
4.00±0.10
0.40
0.05
0.08
0.20
0.60
0.60
0.15
0.20±
±
0.05
0.05
0.89±0.10
0.69
P64F1-40-AA2-1
0.25
(UNIT:mm)
x
y
y1
ZD
ZE
b
ZD
ZE
A
INDEX MARK
A2
A1
e
S
w
A
SwB
B
A
S
y
S
y1
S
S
x
b AB
M
8
7
6
5
4
3
2
1
ABCD
E
FGH
D
E
INDEX MARK
2010 Renesas Electronics Corporation. All rights reserved.
64-PIN PLASTIC FBGA (4x4)
