RL78/G13
CHAPTER 3 CPU ARCHITECTURE
R01UH0146EJ0100 Rev.1.00
135
Sep 22, 2011
3.2.3 ES and CS registers
The ES register is used for data access
and the CS register is used to s
pecify the higher address when a branc
h
instruction is executed.
The default value of the ES register after reset
is 0FH, and that of the CS register is 00H.
Figure 3-27. Configuration of ES and CS Registers
0
0
0
0
ES3
ES2
ES1
ES0
70
ES
6
5
4
3
21
0
0
0
0
CS3
CP2
CP1
CP0
70
CS
6
5
4
3
21
153
155
