RL78/G13 CHAPTER 13 SERIAL INTERFACE IICA
R01UH0146EJ0100 Rev.1.00 705
Sep 22, 2011
13.3 Registers Controlling Serial Interface IICA
Serial interface IICA is controlled by the following eight registers.
Peripheral enable register 0 (PER0)
IICA control register 00 (IICCTL00)
IICA flag register 0 (IICF0)
IICA status register 0 (IICS0)
IICA control register 01 (IICCTL01)
IICA low-level width setting register 0 (IICWL0)
IICA high-level width setting register 0 (IICWH0)
Port mode register 6 (PM6)
Port register 6 (P6)
(1) Peripheral enable register 0 (PER0)
This register is used to enable or disable supplying the clock to the peripheral hardware. Clock supply to a
hardware macro that is not used is stopped in order to reduce the power consumption and noise.
When serial interface IICAm is used, be sure to set bits 6, 4 (IICA1EN, IICA0EN) of this register to 1.
The PER0 register can be set by a 1-bit or 8-bit memory manipulation instruction.
Reset signal generation clears this register to 00H.
Figure 13-5. Format of Peripheral Enable Register 0 (PER0)
Address: F00F0H After reset: 00H R/W
Symbol <7> <6> <5> <4> <3> <2> <1> <0>
PER0
RTCEN
Note 1
IICA1EN
Note 1
ADCEN
IICA0EN
Note 2
SAU1EN
Note 3
SAU0EN
TAU1EN
Note 1
TAU0EN
IICAmEN Control of serial interface IICAm input clock supply
0
Stops input clock supply.
SFR used by serial interface IICAm cannot be written.
Serial interface IICAm is in the reset status.
1
Enables input clock supply.
SFR used by serial interface IICAm can be read/written.
Notes 1. 80, 100, and 128-pin products only.
2. This is not provided in the 20-pin products.
3. This is not provided in the 20, 24, and 25-pin products.
Cautions 1. When setting serial interface IICAm, be sure to set the IICAmEN bit to 1 first. If IICAmEN = 0,
writing to a control register of serial interface IICAm is ignored, and, even if the register is
read, only the default value is read (except for port mode register 6 (PM6) and port register 6
(P6)).
2. Be sure to clear the following bits to 0.
20-pin products: bits 1, 3, 4, 6
24, 25-pin products: bits 1, 3, 6
30, 32, 36, 40, 44, 48, 52, 64-pin products: bits 1, 6
Remark m = 0, 1
