RL78/G13 CHAPTER 30 PACKAGE DRAWINGS
R01UH0146EJ0100 Rev.1.00 1042
Sep 22, 2011
CHAPTER 30 PACKAGE DRAWINGS
30.1 20-pin products
R5F1006AASP, R5F1006CASP, R5F1006DASP, R5F1006EASP
R5F1016AASP, R5F1016CASP, R5F1016DASP, R5F1016EASP
NS
C
DM
M
P
L
U
T
G
F
E
B
K
J
detail of lead end
S
20 11
110
A
H
I
ITEM
B
C
I
L
M
N
20-PIN PLASTIC SSOP (7.62 mm (300))
A
K
D
E
F
G
H
J
P
T
MILLIMETERS
0.65 (T.P.)
0.475 MAX.
0.13
0.5
6.1±0.2
0.10
6.65±0.15
0.17±0.03
0.1±0.05
0.24
1.3±0.1
8.1±0.2
1.2
+0.08
−0.07
1.0±0.2
3°
+5°
−3°
0.25
0.6±0.15
U
NOTE
Each lead centerline is located within 0.13 mm of
its true position (T.P.) at maximum material condition.
S20MC-65-5A4-2
