RL78/G13 CHAPTER 30 PACKAGE DRAWINGS

R01UH0146EJ0100 Rev.1.00 1051

Sep 22, 2011

R5F100GAANA, R5F100GCANA, R5F100GDANA, R5F100GEANA, R5F100GFANA, R5F100GGANA,

R5F100GHANA, R5F100GJANA, R5F100GKANA, R5F100GLANA

R5F101GAANA, R5F101GCANA, R5F101GDANA, R5F101GEANA, R5F101GFANA, R5F101GGANA,

R5F101GHANA, R5F101GJANA, R5F101GKANA, R5F101GLANA

48-PIN PLASTIC WQFN(7x7)

DETAIL OF A PART

SxbA B

ITEM DIMENSIONS

7.00 0.05

0.50

0.05

7.00 0.05

0.75 0.05

0.25

0.05

0.07

0.40 0.10

(UNIT:mm

)

P48K8-50-5B4-3

−

EXPOSED DIE PAD

ITEM

MIN

NOM

MAX

5.45

5.50

EXPOSED

DIE PAD

VARIATIONS

5.55

MIN

NOM MAX

5.45

5.50 5.55
