RL78/G13 CHAPTER 3 CPU ARCHITECTURE
R01UH0146EJ0100 Rev.1.00 147
Sep 22, 2011
Table 3-6. Extended SFR (2nd SFR) List (5/8)
Manipulable Bit Range Address
Special Function Register (SFR) Name
Symbol R/W
1-bit 8-bit 16-bit
After Reset
F0180H
F0181H
Timer counter register 00 TCR00 R
− − √
FFFFH
F0182H
F0183H
Timer counter register 01 TCR01 R
− − √
FFFFH
F0184H
F0185H
Timer counter register 02 TCR02 R
− − √
FFFFH
F0186H
F0187H
Timer counter register 03 TCR03 R
− − √
FFFFH
F0188H
F0189H
Timer counter register 04 TCR04 R
− − √
FFFFH
F018AH
F018BH
Timer counter register 05 TCR05 R
− − √
FFFFH
F018CH
F018DH
Timer counter register 06 TCR06 R
− − √
FFFFH
F018EH
F018FH
Timer counter register 07 TCR07 R
− − √
FFFFH
F0190H
F0191H
Timer mode register 00 TMR00 R/W
− − √
0000H
F0192H
F0193H
Timer mode register 01 TMR01 R/W
− − √
0000H
F0194H
F0195H
Timer mode register 02 TMR02 R/W
− − √
0000H
F0196H
F0197H
Timer mode register 03 TMR03 R/W
− − √
0000H
F0198H
F0199H
Timer mode register 04 TMR04 R/W
− − √
0000H
F019AH
F019BH
Timer mode register 05 TMR05 R/W
− − √
0000H
F019CH
F019DH
Timer mode register 06 TMR06 R/W
− − √
0000H
F019EH
F019FH
Timer mode register 07 TMR07 R/W
− − √
0000H
F01A0H TSR00L
− √
F01A1H
Timer status register 00
−
TSR00 R
− −
√
0000H
F01A2H TSR01L
− √
F01A3H
Timer status register 01
−
TSR01 R
− −
√
0000H
To Next Page
