RL78/G13 CHAPTER 4 PORT FUNCTIONS
R01UH0146EJ0100 Rev.1.00 166
Sep 22, 2011
Table 4-2. Port Configuration (2/2)
Item Configuration
Port • 80-pin products
Total: 74 (CMOS I/O: 64, CMOS input: 5, CMOS output: 1, N-ch open drain I/O: 4)
• 100-pin products
Total: 92 (CMOS I/O: 82, CMOS input: 5, CMOS output: 1, N-ch open drain I/O: 4)
• 128-pin products
Total: 120 (CMOS I/O: 110, CMOS input: 5, CMOS output: 1, N-ch open drain I/O: 4)
Pull-up resistor • 20-pin products Total: 10
• 24-pin products Total: 12
• 25-pin products Total: 12
• 30-pin products Total: 17
• 32-pin products Total: 18
• 36-pin products Total: 20
• 40-pin products Total: 21
• 44-pin products Total: 23
• 48-pin products Total: 26
• 52-pin products Total: 30
• 64-pin products Total: 40
• 80-pin products Total: 52
• 100-pin products Total: 67
• 128-pin products Total: 95
To Next Page
