RL78/G13 CHAPTER 4 PORT FUNCTIONS

R01UH0146EJ0100 Rev.1.00 204

Sep 22, 2011

Figure 4-28. Block Diagram of P51, P56, P57

P51, P56, P57

PORT

P-ch

PU5

PM5

PM51,

PM56, PM57

PU51,

PU56, PU57

Output latch

(P51, P56, P57)

Selector

Internal bus

P5: Port register 5

PU5: Pull-up resistor option register 5

PM5: Port mode register 5

RD: Read signal

WR××: Write signal
