RL78/G13 CHAPTER 4 PORT FUNCTIONS

R01UH0146EJ0100 Rev.1.00 238

Sep 22, 2011

Figure 4-54. Block Diagram of P125 to P127

P125 to P127

PORT

P-ch

PU12

PM12

P12

PM125 to PM127

PU125 to PU127

Output latch

(P125 to P127)

Selector

Internal bus

P12: Port register 12

PU12: Pull-up resistor option register 12

PM12: Port mode register 12

RD: Read signal

WR××: Write signal
