RL78/G13
CHAPTER 4 PORT FUNCTIONS
R01UH0146EJ0100 Rev.1.00
248
Sep 22, 2011
Figure 4-63. Blo
ck Diagram of P147
P147/ANI18
WR
PU
RD
WR
PORT
WR
PM
PU147
PM147
EV
DD
P-ch
PU14
PM14
P14
A/D converter
WR
PMC
PMC14
PMC147
Output latch
(P147)
Selector
Internal bus
P14:
Port register 14
PU14:
Pull-up resistor option register 14
PM14:
Port mode regi
ster 14
PMC14:
Port mode control register 14
RD: Read
sign
al
WR
××
: Write
signal
