RL78/G13 CHAPTER 4 PORT FUNCTIONS

R01UH0146EJ0100 Rev.1.00 250

Sep 22, 2011

Figure 4-64. Block Diagram of P150 to P156

P150/ANI8 to P156/ANI14

PORT

PM150 to PM156

PM15

A/D converter

P15

Output latch

(P150 to P156)

Selector

Internal bus

ADPC

ADPC3 to ADPC0

ADPC

0:Analog input

1:Digital I/O

ADPC: A/D port cofiguration register

P15: Port register 15

PM15: Port mode register 15

RD: Read signal

WR××: Write signal
