RL78/G13 CHAPTER 5 CLOCK GENERATOR
R01UH0146EJ0100 Rev.1.00 317
Sep 22, 2011
Table 5-3. CPU Clock Transition and SFR Register Setting Examples (5/5)
(11) • STOP mode (H) set while CPU is operating with high-speed on-chip oscillator clock (B)
• STOP mode (I) set while CPU is operating with high-speed system clock (C)
(Setting sequence)
Status Transition Setting
(B) → (H)
−
In X1 oscillation
Sets the OSTS
register
(C) → (I)
External main
system clock
Stopping peripheral
functions that cannot
operate in STOP mode
−
Executing STOP
instruction
(12) CPU changing from STOP mode (H) to SNOOZE mode (J)
For details about the setting for switching from the STOP mode to the SNOOZE mode, see 11.8 SNOOZE Mode
Function, 12.5.7 SNOOZE mode function and 12.6.3 SNOOZE mode function.
Remark (A) to (J) in Table 5-3 correspond to (A) to (J) in Figure 5-15.
