RL78/G13 CHAPTER 6 TIMER ARRAY UNIT

R01UH0146EJ0100 Rev.1.00 387

Sep 22, 2011

Figure 6-42. Example of Basic Timing of Operation as External Event Counter

TSmn

TEmn

TImn

TDRmn

TCRmn

0003H 0002H

0000H

INTTMmn

4 events

3 events

Remarks 1. m: Unit number (m = 0, 1), n: Channel number (n = 0 to 7)

2. TSmn: Bit n of timer channel start register m (TSm)

TEmn: Bit n of timer channel enable status register m (TEm)

TImn: TImn pin input signal

TCRmn: Timer count register mn (TCRmn)

TDRmn: Timer data register mn (TDRmn)
