RL78/G13 CHAPTER 6 TIMER ARRAY UNIT

R01UH0146EJ0100 Rev.1.00 396

Sep 22, 2011

Figure 6-50. Example of Basic Timing of Operation as Input Pulse Interval Measurement (MDmn0 = 0)

TSmn

TEmn

TImn

TDRmn

TCRmn

0000H

INTTMmn

FFFFH

OVF

Remarks 1. m: Unit number (m = 0, 1)n: Channel number (n = 0 to 7)

2. TSmn: Bit n of timer channel start register m (TSm)

TEmn: Bit n of timer channel enable status register m (TEm)

TImn: TImn pin input signal

TCRmn: Timer count register mn (TCRmn)

TDRmn: Timer data register mn (TDRmn)

OVF: Bit 0 of timer status register mn (TSRmn)
