RL78/G13 CHAPTER 7 REAL-TIME CLOCK
R01UH0146EJ0100 Rev.1.00 441
Sep 22, 2011
Table 7-2 shows the relationship between the setting value of the AMPM bit, the hour count register (HOUR) value, and
time.
Table 7-2. Displayed Time Digits
24-Hour Display (AMPM = 1) 12-Hour Display (AMPM = 1)
Time HOUR Register Time HOUR Register
0 00H 12 a.m. 12H
1 01H 1 a.m. 01H
2 02H 2 a.m. 02H
3 03H 3 a.m. 03H
4 04H 4 a.m. 04H
5 05H 5 a.m. 05H
6 06H 6 a.m. 06H
7 07H 7 a.m. 07H
8 08H 8 a.m. 08H
9 09H 9 a.m. 09H
10 10H 10 a.m. 10H
11 11H 11 a.m. 11H
12 12H 12 p.m. 32H
13 13H 1 p.m. 21H
14 14H 2 p.m. 22H
15 15H 3 p.m. 23H
16 16H 4 p.m. 24H
17 17H 5 p.m. 25H
18 18H 6 p.m. 26H
19 19H 7 p.m. 27H
20 20H 8 p.m. 28H
21 21H 9 p.m. 29H
22 22H 10 p.m. 30H
23 23H 11 p.m. 31H
The HOUR register value is set to 12-hour display when the AMPM bit is “0” and to 24-hour display when the AMPM bit
is “1”.
In 12-hour display, the fifth bit of the HOUR register displays 0 for AM and 1 for PM.
