Page #462 background image
RL78/G13 CHAPTER 7 REAL-TIME CLOCK
R01UH0146EJ0100 Rev.1.00 443
Sep 22, 2011
(9) Week count register (WEEK)
The WEEK register is an 8-bit register that takes a value of 0 to 6 (decimal) and indicates the count value of
weekdays.
It counts up in synchronization with the day counter.
When data is written to this register, it is written to a buffer and then to the counter up to 2 clocks (f
RTC) later. Set a
decimal value of 00 to 06 to this register in BCD code. If a value outside the range is set, the register value returns
to the normal value after 1 period.
The WEEK register can be set by an 8-bit memory manipulation instruction.
Reset signal generation clears this register to 00H.
Figure 7-10. Format of Week Count Register (WEEK)
Address: FFF95H After reset: 00H R/W
Symbol 7 6 5 4 3 2 1 0
WEEK 0 0 0 0 0 WEEK4 WEEK2 WEEK1
Cautions 1. The value corresponding to the month count register (MONTH) or the day count register (DAY)
is not stored in the week count register (WEEK) automatically. After reset release, set the
week count register as follow.
Day WEEK
Sunday 00H
Monday 01H
Tuesday 02H
Wednesday 03H
Thursday 04H
Friday 05H
Saturday 06H
2. When it reads or writes from/to the register while the counter is in operation (RTCE = 1),
follow the procedures described in the section 7.4.3 Reading/writing real-time clock.
<R>
<R>
