RL78/G13 CHAPTER 7 REAL-TIME CLOCK
R01UH0146EJ0100 Rev.1.00 445
Sep 22, 2011
(12) Watch error correction register (SUBCUD)
This register is used to correct the watch with high accuracy when it is slow or fast by changing the value that
overflows from the sub-count register to the second count register (SEC) (reference value: 7FFFH).
The SUBCUD register can be set by an 8-bit memory manipulation instruction.
Reset signal generation clears this register to 00H.
Figure 7-13. Format of Watch Error Correction Register (SUBCUD)
Address: FFF99H After reset: 00H R/W
Symbol 7 6 5 4 3 2 1 0
SUBCUD DEV F6 F5 F4 F3 F2 F1 F0
DEV Setting of watch error correction timing
0 Corrects watch error when the second digits are at 00, 20, or 40 (every 20 seconds).
1 Corrects watch error only when the second digits are at 00 (every 60 seconds).
Writing to the SUBCUD register at the following timing is prohibited.
• When DEV = 0 is set: For a period of SEC = 00H, 20H, 40H
• When DEV = 1 is set: For a period of SEC = 00H
F6 Setting of watch error correction value
0 Increases by {(F5, F4, F3, F2, F1, F0) – 1} × 2.
1 Decreases by {(/F5, /F4, /F3, /F2, /F1, /F0) + 1} × 2.
When (F6, F5, F4, F3, F2, F1, F0) = (*, 0, 0, 0, 0, 0, *), the watch error is not corrected. * is 0 or 1.
/F5 to /F0 are the inverted values of the corresponding bits (000011 when 111100).
Range of correction value: (when F6 = 0) 2, 4, 6, 8, … , 120, 122, 124
(when F6 = 1) –2, –4, –6, –8, … , –120, –122, –124
The range of value that can be corrected by using the watch error correction register (SUBCUD) is shown below.
DEV = 0 (correction every 20 seconds) DEV = 1 (correction every 60 seconds)
Correctable range –189.2 ppm to 189.2 ppm –63.1 ppm to 63.1 ppm
Maximum excludes
quantization error
± 1.53 ppm ± 0.51 ppm
Minimum resolution ± 3.05 ppm ± 1.02 ppm
Remark If a correctable range is − 63.1 ppm or lower and 63.1 ppm or higher, set 0 to DEV.
