(9) Serial channel stop register m (STm)
The STm register is a trigger register that is used to enable stopping communication/count by each channel.
When 1 is written a bit of this register (STmn), the corresponding bit (SEmn) of serial channel enable status
register m (SEm) is cleared to 0 (operation is stopped). Because the STmn bit is a trigger bit, it is cleared
immediately when SEmn = 0.
The STm register can set written by a 16-bit memory manipulation instruction.
The lower 8 bits of the STm register can be set with a 1-bit or 8-bit memory manipulation instruction with STmL.
Reset signal generation clears the STm register to 0000H.
Figure 12-13. Format of Serial Channel Stop Register m (STm)
Address: F0124H, F0125H (ST0) After reset: 0000H R/W
Symbol 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
ST0 0 0 0 0 0 0 0 0 0 0 0 0 ST03 ST02 ST01 ST00
Address: F0164H, F0165H (ST1) After reset: 0000H R/W
Symbol 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
ST1 0 0 0 0 0 0 0 0 0 0 0 0 ST13 ST12 ST11 ST10
STm
n
Operation stop trigger of channel n
0 No trigger operation
1
Clears the SEmn bit to 0 and stops the communication operation
Note
.
Note Communication stops while holding the value of the control register and shift register, and the status of the
serial clock I/O pin, serial data output pin, and each error flag (FEFmn: framing error flag, PEFmn: parity
error flag, OVFmn: overrun error flag).
Caution Be sure to clear bits 15 to 4 of the ST0 register and bits 15 to 4 of the ST1 register to “0”.
Remarks 1. m: Unit number (m = 0, 1), n: Channel number (n = 0 to 3)
2. When the STm register is read, 0000H is always read.
