RL78/G13 CHAPTER 13 SERIAL INTERFACE IICA

R01UH0146EJ0100 Rev.1.00 764

Sep 22, 2011

(ii) When WTIM0 = 1

ST AD6 to AD0 R/W ACK D7 to D0 D7 to D0ACK ACK SP

3 2 1

1: IICS0 = 10001110B

2: IICS0 = 01000100B

3: IICS0 = 00000001B

Remark

: Always generated

: Generated only when SPIE0 = 1

(d) When loss occurs due to restart condition during data transfer

(i) Not extension code (Example: unmatches with SVA0)

ST AD6 to AD0 R/W ACK D7 to Dn AD6 to AD0 ACK SPST R/W D7 to D0 ACK

3 2 1

1: IICS0 = 1000×110B

2: IICS0 = 01000110B

3: IICS0 = 00000001B

Remark

: Always generated

: Generated only when SPIE0 = 1

×: Don’t care

n = 6 to 0
