Renesas RL78/G13

RL78/G13 CHAPTER 28 INSTRUCTION SET
R01UH0146EJ0100 Rev.1.00 974
Sep 22, 2011
Table 28-5. Operation List (13/17)
Notes 1. Number of CPU clocks (f
CLK) when the internal RAM area, SFR area, or extended SFR area is accessed, or
when no data is accessed.
2. Number of CPU clocks (f
CLK) when the program memory area is accessed.
Remark Number of clock is when program exists in the internal ROM (flash memory) area. If fetching the instruction
from the internal RAM area, the number becomes double number plus 3 clocks at a maximum.
Clocks Flag
Instruction
Group
Mnemonic Operands Bytes
Note 1 Note 2
Clocks
Z AC CY
ROR A, 1 2 1
−
(CY, A7 ← A0, Am-1 ← Am)×1 ×
ROL A, 1 2 1
−
(CY, A0 ← A7, Am+1 ← Am)×1 ×
RORC A, 1 2 1
−
(CY ← A0, A7 ← CY, Am-1 ← Am)×1 ×
ROLC A, 1 2 1
−
(CY ← A7, A0 ← CY, Am+1 ← Am)×1 ×
AX,1 2 1
−
(CY ← AX15, AX0 ← CY, AXm+1 ← AXm) ×1 ×
Rotate
ROLWC
BC,1 2 1
−
(CY ← BC
15, BC0 ← CY, BCm+1 ← BCm) ×1 ×
CY, A.bit 2 1
−
CY ← A.bit ×
A.bit, CY 2 1
−
A.bit ← CY
CY, PSW.bit 3 1
−
CY ← PSW.bit ×
PSW.bit, CY 3 4
−
PSW.bit ← CY × ×
CY, saddr.bit 3 1
−
CY ← (saddr).bit ×
saddr.bit, CY 3 2
−
(saddr).bit ← CY
CY, sfr.bit 3 1
−
CY ← sfr.bit ×
sfr.bit, CY 3 2
−
sfr.bit ← CY
CY,[HL].bit 2 1 4 CY ← (HL).bit ×
[HL].bit, CY 2 2
−
(HL).bit ← CY
CY, ES:[HL].bit 3 2 5 CY ← (ES, HL).bit ×
MOV1
ES:[HL].bit, CY 3 3
−
(ES, HL).bit ← CY
CY, A.bit 2 1
−
CY ← CY ∧ A.bit ×
CY, PSW.bit 3 1
−
CY ← CY ∧ PSW.bit ×
CY, saddr.bit 3 1
−
CY ← CY ∧ (saddr).bit ×
CY, sfr.bit 3 1
−
CY ← CY ∧ sfr.bit ×
CY,[HL].bit 2 1 4 CY ← CY ∧ (HL).bit ×
AND1
CY, ES:[HL].bit 3 2 5 CY ← CY ∧ (ES, HL).bit ×
CY, A.bit 2 1
−
CY ← CY ∨ A.bit ×
CY, PSW.bit 3 1
−
CYX ← CY ∨ ∨PSW.bit ×
CY, saddr.bit 3 1
−
CY ← CY ∨ (saddr).bit ×
CY, sfr.bit 3 1
−
CY ← CY ∨ sfr.bit ×
CY, [HL].bit 2 1 4 CY ← CY ∨ (HL).bit ×
Bit
manipulate
OR1
CY, ES:[HL].bit 3 2 5 CY ← CY ∨ (ES, HL).bit ×
