Renkforce RF2000 v2 Series User Manual

28
Conguration
Feed rate MaxX:500 Max.speedoftheX-axis
MaxY:500 Max.speedoftheY-axis
Max Z: 50 Max. speed of the Z-axis
HomeX:80 Max.speedoftheX-axiswhenmovingtothehomeposition
HomeY:80 Max.speedoftheY-axiswhenmovingtothehomeposition
Home Z: 10 Max. speed of the Z-axis when moving to the home position
Z Calibration Scan Quick printing plate calibration
Scan PLA Printing plate calibration with typical PLA-temperatures
Scan ABS Printing plate calibration with typical ABS-temperatures
Align Extruders Alignment of the two extruders without printing plate calibration
With this point, the two extruders can be aligned subsequently without printing plate scan. The
extruders must be manually heated to the desired temperature.
Z Offset ShiftsthedistancebetweenthenozzleandheatingplateinZ-directionbythespeciedvalue
(standard = 0 µm)
Position Z Z: 0.00 mm MovesZ-axistoanadjustableposition;
Move with the arrows "up"/"down" (1)
End stop min: Displays the limit switch condition min. (light barrier)
End stop max: Displaysthelimitswitchconditionmax.(bottomattheY-plate)
Single Move Switchesthelengthofthemovementperpushofthebutton;switchwiththe
arrow "right" (1):
Single Move = Moves until the button is released
1 mm/10 mm/50 mm = Movement by the chosen length in mm
SingleSteps=Movementbysinglesteps;1pushofbutton=1singlestep
Set Z Matrix: 1 Up to 9 heat bed scans can be saved
Restore Defaults Resets the settings to defaults
