Move to the offset position
• Firstmoveallaxestotheirhomeposition.
For this, click the unlabelled house icon.
IftheguresintheeldsX,YandZarered,nohomeposi-
tion has been moved to yet. The software accordingly
does not know where the printer axes are currently locat-
ed. Once the home positions are reached, the colour turns
black.
• NowmovetheX-axistothepositionpreviouslyread.
• Forthis,enterthecommand"G1 X160" (without quotation marks)
in the eld "G-Code" and click"Send". Replace 160 by your X-
value.
 TheprintermovestheX-axistotheposition.Inourexample,thisis
theX-position160.
Whenthepositionisreached,theeldXwillshowthecur-
rent position. In our example, this is 160.00.
