Property HCQ02 HCT02
EtherNet Engineering Port ■
sercos III Master Port ■
Master communication
Embedded PC ■
Multi-protocol EtherNet -
PROFIBUS -
Inputs / outputs
Digital inputs
1)
Thereof probes
32
4
Digital outputs
1)
16
Analog inputs 0
Analog outputs 0
Relay contacts 1 N/O
Switching frequencies
4 kHz ■
8 kHz ■
■ Available
- Not available
1) On-board connection points; can be extended with optional modules
Fig.1-4: Properties
