10 Identifying and Checking the Delivered Components
10.1 Type Plate
10.1.1 Arrangement
Fig.10-1: Type Plate Arrangement
10.1.2 Design
Type Plate (Power Sections, Sup‐
ply Units)
1 Device type
2 Part number
3 Serial number
4 Bar code
5 Country of manufacture
6 Production week; e.g. 08W23 meaning year 2008, week 23
7 Hardware index
Fig.10-2: Type Plate (Power Sections, Supply Units)
